Hilti PROFIS Detection software is designed to analyze data from Hilti concrete scanners to locate hidden metal and non-metal objects before you drill, core, saw or cut – for non-destructive structural analysis. Our method can design applications, which aren’t covered by Eurocode 2 or for shorter anchorage lengths.ĭesign fixings for façades, lift shafts and other anchor channel applications, adding Hilti’s expertise on anchor channels to your own. You can design for both Eurocode 2 or use Hilti’s design method.
Hilti PROFIS Rebar can design a wide range of rebar applications. We also offer an extensive BIM/CAD library of Hilti products.ĭesign a wide range of anchoring applications in concrete and masonry, using SOFA, our own Hilti design method or those based on international codes. Cut out manual transfers of data and potential error, collaborate in real-time with your team through our cloud-based solutions. Note that the length you set must exist in your bolt catalog.Our 3D PROFIS design software is designed to speed up and simplify your engineering design, by automating complex calculations and minimizing the need for detailed engineering expertise.Ĭreate virtual designs in 3D to help to prevent clashes and save time on the jobsite. Use a negative number in this field to force the length of the bolt.
For an epoxy or expansion type anchor that does not use the nut and washer, the length must be set in the Cut Length field. Normally, a bolt length is calculated based on the grip (thickness of materials being bolted).
When creating these bolts in the model, make sure to pick the standard you have defined, and the diameter. This creates an assdb.db file (bolt assembly catalog) that can be used in future models. Even with something like an epoxy anchor, where these are not used, they need to have a value in the Assembly.įinally, click OK and save changes to model folder. Adjust other values to choose washer and nut types. This is the full name which is shown in the bolt assemblies list in the Bolt Assembly Catalog, and in the Bolt standard list box in the Bolt properties dialog box when invoked from the model.ĥ.It is usually the commercial name for a specific bolt. Short name is used in marking and reports.Change the properties of the bolt assembly in the right hand side. Make sure that the new name shows in the drop down at the bolt head in the picture on the right.Ĥ. Give the Hilti Kwik bolt assembly a name and click Add.ģ.
